Hydraulic Steering Helm - 23CC (Multiflex)

Multiflex 23cc Hydraulic Steering Helm Pump

Port Threads (UNEF): 9/16-24

Relief Pressure: 70 Bar

Recommended Steering Wheel Diameter: 350mm

Weight: 4.2kg

Key Features

• Ball bearing piston race
• Built-in Lock Valve to safeguard feedback from the rudder
• Integral Relief Valve to protect the steering system from excess pressure
• 3/4” standard tapered shaft
• Easily accessible Lock Valve Seals and Shaft Seal for replacement
• Helm mounting is designed in such a way that it is easily interchangeable with other brands
